22 inch LCD shelf mount remote control digital signage stretch bar screen shelves lcd led display
22 inch LCD shelf mount remote control digital signage stretch bar screen shelves lcd led display
Couldn't load pickup availability
SPECIFICATIONS
Brand Name: NoEnName_Null
Origin: Mainland China
19 21.5 28 38 49 inch hd ultra-wide stretched advertising lcd bar display
Bar screen android tablet for business | ||
System |
CPU |
Quad core cortex A9,1.6G,RK3188 |
RAM |
1GB |
|
Internal memory |
8GB |
|
Operation system |
Android 4.4 Default |
|
Display |
Panel |
19"bar screen |
Resolution |
1920*360 |
|
Active area |
476.64(H)x 89.37 mm(V) |
|
Viewing angle |
89/89/89/89(L/R/U/D) |
|
Display mode |
Nomally black ,IPS |
|
Contrast ratio |
1200 |
|
Luminance |
300cd/m2 |
|
Aspect Ratio |
Bar screen |
|
Network |
WiFi |
802.11b/g/n |
Ethernet |
10M/100M ethernet |
|
Buletooth |
BT 4.0 |
|
Interface |
USB Host x 3 |
USB 2.0 |
USB OTG |
USB OTG |
|
SD card slot |
SD/MMC card slot |
|
Earphone |
3.5mm earphone |
|
Power Jack |
DC input |
|
RJ45 |
Ethernet |
|
Media plays |
Video format |
MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc. |
Photo |
jpeg |
|
Other |
VESA |
Wall mounting |
Language |
Multi-language |
|
Working temp |
0--40degree |
|
Power consumption |
30W |
|
Accessories |
Adapter |
Adapter,12V,3A |
User manual |
yes |
|
What is the Specification of our kiosk?
Index |
Model |
GT43B |
Outside area (mm) |
720.5(W)*162(H)*56.4(D) |
|
Display area (mm) |
698.5(W)*140(H) |
|
Size |
28 inch |
|
Display |
LCD |
|
Dot pitch |
0.1845(H) *0.1845(V) |
|
Resolution |
1920x758 |
|
Brightness |
500-700cd (optional) |
|
Contrast |
3000:1 |
|
Viewing angle |
89/89 |
|
Response time |
8ms |
|
Color |
1677 million color |
|
Color Gamut |
92% |
|
Connection method |
Input method |
HDMI/VGA/DVI/BNC,Network board/(optional) |
Video input |
CVBS |
|
Control method |
RS-232 485 |
|
Network function |
optional |
|
Power |
Power consumption |
26W |
Standby power consumption |
5W |
|
Power management |
DC 24V |
|
Mechanical indicators |
Stand installation |
Need to be customized |
Weight |
5.18Kg |
|
Operating environment |
Operating temperature |
0℃~ 50℃ |
Humidity |
10~80% |
|
Altitude |
3000m |
|
Mean Time Between Failures |
50000 hours |
|
Auxiliary material |
System equipment connection wire |
customized |
Display unit bracket |
optional |
|
Connection wires |
, Power line, serial control line |
MODEL |
GT49M |
Screen Size |
49 inch |
Display Area |
1209.6*320mm |
Resolution |
1920*508 |
Brightness |
500cd/㎡ |
Contrast |
1000:1 |
Color |
16.7M/8bit |
Viewing Angle |
89°/89°/89°/89°(L/R/U/D) |
Touch Screen |
Optional |
I/O |
HDMI*1, VGA*1 |
All-in-one Solution |
Optional |
Power Input |
