Golf carts color White, Red, Green, Blue,Black, Silver, grey ect. color , and seats number can be customized

Controller

Curtis or Enpower Controller(full intelligent electric control)

Key Components

Motor

4KW/5KW/7KW AC motor

Battery

12V100AH/pc, 4pcs/48V(Maintenance-free battery)

Passenger Capacity

(2+2)

Range (Loaded) *

90-100kms

Max.speed

35-45km/h

Min. Turning Radius

3.7m

Performance

Max. Gradeability

20%-30%

and

Max. Loading Weight

320kgs

Dimensions

Net Weight

510kgs

Overall Dimensions

3200X1350X2000mm

Body and Frame

Frame (Chassis)

Welded steel framework, with anti-rust treatment of acid washing, phosphating and electro-coating

Body and Roof

PP plastic front body and rear body; PP vacuum form roof

Windshield

Organic plastic windshield

Roof supports

Carbon Steel, powder coated

Backrest and Seat

Reborn Sponge,artificial leather + plastic armrest

Floor

Galvanized Steel plate and anti-slip rubber floor mat

Dashboard

Plastic in black, with 4 cup holders, 2 glove storage box,forward/reverse switch, battery capacity indicator, ignition key

Side trim

Plastic

Sider mirror

2pcs, foldable

Electric System

Lighting system and horn

All LED lights, 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with 20A voltage reducer (converting from 72V to 12V), electric horn.

Digital Meter

LCD screen, with speedometer, odometer, battery power meter and various indicators

Charger

Smart charger,input 110V-240V~50Hz-60Hz, output 72V, 20A

Steering, Brake, Transmission and Suspension

Steering System

Single-stage rack and pinion steering system, automatic rocker compensating function

Brake system

4 Wheels hydraulic front disc rear drum brake, regen brake

Accelerator

Stepless speed change

Driving mode

Rear axle two stage deceleration, motor direct driving

Rear axle

Integrated, Gear ratio12.49:1

Suspension system

Front MacPherson Independent and rear plate leaf spring + cylinder hydraulic shock absorber

Wheel & Tyre

205/50-10 Vacuum radial tire. Aluminum alloy rim
